50 Meter · Rifle & Pistol
Tachus 50 Electronic Target System
For 50 Meter Small bore Rifle (.22 calibre) and 50 Meter Free Pistol ISSF events, with live acoustic scoring on a connected screen.
Quotes answered within one working day.
↓ Download product brochure (PDF)
- Events
- 50 Meter Small bore Rifle · 50 Meter Free Pistol
- Detection
- Acoustic sensors with a rubber roll
- Connection
- Cable to Windows laptop or Android tablet
- Warranty
- 2 years · extendable up to 8 years
Product overview
Built for the discipline
Tachus 50 Electronic Target System is suited to 50 Meter Small bore Rifle and 50 Meter Free Pistol ISSF shooting events. It uses a rubber roll and comes with Tachus 50 Scoring Software.
The target connects by cable to a Windows laptop or Android tablet.
Supported events
- 50 Meter Small bore Rifle
- 50 Meter Free Pistol
Compliant with ISSF rules and regulations for the supported events. Tachus does not claim ISSF certification.
Best suited to
- Academies and ranges adding 50 Meter electronic lanes
- Institutions training rifle shooters for 50 Meter events
- Ranges replacing manual 50 Meter scoring workflows
Acoustic scoring
How detection works
- 01The bullet passes through a rubber roll on the target unit.
- 02The impact produces sound waves that are detected by acoustic sensors.
- 03Sensor data is converted into electrical signals and processed to calculate the shot position.
- 04The score and placement appear in real time on the connected computer.
Hardware highlights
- Rubber roll for 50 Meter Small bore Rifle and 50 Meter Free Pistol ammunition
- Simplified installation compared with conventional 50 Meter electronic targets
- Sturdy cable connection to the computer at the firing point
- Mounting stand supplied with the system
Software capabilities
- Live shot location visualisation
- Decimal scores with directional data
- Series and match totals
- Pinch zoom and zoom control on the target view
- Customisable training sessions
- Windows scoring software and an Android application optimized for tablets in portrait orientation
- 3P applications for Tachus 50 Electronic Target System on Windows and Android, for training across kneeling, prone and standing
Installation
- Cable connection from the 50 Meter target line to a Windows laptop or Android tablet at the firing point
- Designed for simpler installation and upkeep than conventional 50 Meter systems
- Installation and service at the range provided by Tachus
Maintenance & support
- Replace the rubber roll as it wears
- Warranty for two years, extendable up to eight years
- Support available by phone and WhatsApp from the Bengaluru team
Technical specifications
| Shooting distance | 50 Meter |
|---|---|
| Events | 50 Meter Small bore Rifle, 50 Meter Free Pistol (compliant with ISSF rules and regulations) |
| Detection method | Acoustic sensors with a rubber roll |
| Score display | Live decimal scores with direction |
| Reports | Series and match totals, PDF export |
| Connection | Cable to Windows laptop or Android tablet |
| Scoring applications | Windows software and Android tablet application (portrait orientation) |
| 3P rifle training | Applications for Tachus 50 Electronic Target System on Windows and Android |
| Mounting | Stand supplied |
| Installation and service | Provided by Tachus at the range |
| Warranty | 2 years; extendable up to 8 years |
Specifications reflect the information Tachus publishes today. For dimensions, tolerances and current OS support, request the latest specification sheet from our team.
Common questions
Which events does the Tachus 50 Electronic Target System cover?
The 50 Meter Small bore Rifle events and 50 Meter Free Pistol. If you also need 10 Meter air rifle or air pistol on the same lane, look at the Tachus 50/10 Electronic Target System.
What is the warranty?
The Tachus 50 Electronic Target System includes a warranty for two years, which can be extended up to eight years.
What does it need at the firing point?
Every Tachus model includes Windows scoring software and an Android application optimized for tablets in portrait orientation. Contact our team to confirm current device and connection requirements.
Can I train for 50 Meter Small bore Rifle 3 Positions with Tachus?
Yes. Tachus 50 Electronic Target System includes 3P applications for Windows and Android. The applications support training across the kneeling, prone and standing positions.
Are the mounting stand and installation at the range included?
Yes. Tachus supplies a mounting stand and provides installation and service at the range for the Tachus 50 Electronic Target System.
More answers in the full FAQ.
Related
Also consider
50 Meter / 10 Meter
Tachus 50/10 Electronic Target System
One system for 50 Meter Small bore Rifle and 10 Meter Air Rifle and Air Pistol. Change configurations in about ten minutes instead of buying two target systems.
25 Meter
Tachus 25 Electronic Target System
For 25 Meter Sports Pistol and Standard Pistol ISSF events, with fast acoustic scoring and range lights controlled through the software.
Next step
Plan your 50 Meter lanes with Tachus
Share your discipline, lane count and location. Our sales team replies with a quotation or consultation within one working day.
